Wind-solar, off/on-grid, hybrid grid systems totaling 10KW are enough to meet the daily use of most households. System components include: wind turbine + high wind turbine tower + wind controller + solar panel + mounting bracket+combiner box + hybrid inverter + lithium battery + accessories.
Customized 3-10KW Solar Energy System Hybrid Wind and Solar Power Generator
Product Origin:China
Shipping Port:Shanghai
Lead Time:15-30days
Battery Type:Lithium Ion
Solar Panels :36V
Color:White
Warranty:2 Years
Product Param
| WON-WT-HG3000 | WON-WT-HG5000 | WON-WT-HG10000 | |
| Rated Power | 3kw | 5kw | 10kw |
| Max Power | 3.5kw | 5.5kw | 12kw |
| Start-up Wind Speed | 2.5m/s | 2.5m/s | 2.5m/s |
| Rated Wind Speed | 11m/s | 11m/s | 11m/s |
| Survival Wind Speed | 45.0m/s | 45.0m/s | 45.0m/s |
| Rated Voltage | 96/120V | 120/220V | 220/380V |
| Wheel Diameter | 5.2m | 6.1m | 7.8m |
| TOP N.W | 216kg | 285kg | 400kg |
| Number of Blades | 3( Reinforced glass fiber ) | ||
| Generator | Three phase AC permanent magnet synchronous generator | ||
| Control System | Electromagnetic/Wind wheel partial side | ||
| Direction Regulation Method | Automatically adjust windward direction | ||
| Working Temperature | -40°-80℃ | ||
Product Briefing
